VMPET-GZ series is designed for customers who need stronger barrier performance than standard metallized PET film. The brochure lists three grades: VMPET-GZ, VMPET-GZ01 and VMPET-GZ03.

Common substrate thickness is 10-25 μm, with width and length produced to customer requirements. The technical table provides reference values for 12 μm film.

The film is intended for high-barrier laminates and for customers evaluating replacement of some aluminum-foil-based structures. Final suitability depends on the complete laminate, sealing layer and filling process.

• 12 μm reference thickness for VMPET-GZ, VMPET-GZ01 and VMPET-GZ03.
• OTR: 0.70 / 0.40 / 0.25 cc/m²·24h respectively, tested to ASTM D-3985.
• WVTR: 0.80 / 0.60 / 0.25 g/m²·24h respectively, tested to ASTM F-1249.
• Aluminum-layer thickness: ≥ 2.2 / ≥ 2.5 / ≥ 2.5 OD respectively.
• Aluminum-layer adhesion: 2.6 / 2.8 / 3.0 N/15mm respectively.
• Surface tension: 52 mN/m on the metallized side and 42 mN/m on the non-metallized side.
• Tensile strength: 220 MPa MD and 230 MPa TD; elongation at break: 118% MD and 107% TD.
• Metallic appearance and light-shielding performance for light-sensitive products.

• Packaging for dried fruit, tea, coffee, chocolate, dehydrated food, dried flavorings and pharmaceuticals.
• Packaging and decorative applications for electronics, labels, cosmetics and metal products.
• A high-barrier option for customers evaluating replacement of some aluminum-foil-based laminates.
• Final barrier, printing, lamination and sealing performance should be validated in the customer's package structure.

Important Notes:

The above data, obtained from our internal testing, is provided for reference only to assist customers in sample evaluation or product use.

The final performance of the product depends on specific production processes, and improper use may cause irreversible damage.

As equipment, processing condtions, and end-use requirements vary across manufacturers, our company shall only be responsible for the

performance of the film itself.

FAQ

What grades of ultra-high barrier metallized PET film are listed?

The existing page lists VPET-GZ, VPET-GZ01 and VPET-GZ03.

What are the key characteristics of this film?

The page describes high moisture barrier, ultra-high oxygen barrier, light blocking and metallic gloss.

What is this film mainly used for?

The page lists dried fruits, tea, coffee, chocolate, dehydrated foods, medicines, electronics, decorative materials, labels, cosmetics and metal-product packaging.
